SYSTEM: 2 way vented box loudspeaker.
CABINET: Lute shape design, combination of sandwich construction, obtained using 20 hand selected wood layers and solid maple, quality graded and oriented for carefully optimized resonances and standing waves control.
TWEETER: 25 mm ultra dynamic ring radiator-driver, with dual toroidal wave-guide.
MIDRANGE: 150 mm cone driver with Symmetric Drive Motor System and selected
black wood fiber cone, high resolution, treated for break-up control.
Dynamic linear suspension.
CROSS-OVER: Non-resonant first order design, optimized phase characteristics for optimal space/time performance, crossing point 2500Hz
FREQUENCY RESPONSE: 50 Hz 30.000 Hz, tuning ports included.
SENSITIVITY: 88 db SPL (2.83 V/1m).
NOMINAL IMPEDANCE: 4 ohms.
POWER HANDLING: 40W 150W, without clipping.
FINISH: Natural maple multicoated with medium gloss ecologically sensitive lacquer.
DIMENSIONS: 202 x 365 x 353 mm (WxDxH). WEIGHT: 18.4 Kg per pair net weight/ 22.3 Kg per pair shipping weight.
OPTIONAL DEDICATED STAND: 415 x 310 x 710 mm (WxDxH). WEIGHT: 22.6 Kg per pair net weight/ 26.4 Kg per pair shipping weight.
TOTAL DIMENSIONS: 415 x 400 x 1065 mm (WxDxH).
Heir to Sonus Faber's history of creating compact, versatile speakers, the Auditor M meets the most demanding listener's insistence on superior sound.
