Resolution 1280x720 16:9 Projection system Texas Instruments Mustang HD2+TM 720p DLP Enhancement New Faroudja DCDi TM FLI2310 Optic Carl Zeiss Projection Lens: F/2.7 (wide), F/3.1 (tele) Throw Ratio 1.67:1 - 2.08:1 (distance/width) Colour Wheel 7 segments (RGBRGBG) Contrast ratio 2300:1 full on / full off Lamp Dual mode : 220W UHP (3000 hours)/250W UHP (2000 hours) Brightness 1200 lumens Colors 16.7 millions simultaneously displayable Installation Front, Rear, Table, Ceiling (Ceiling bracket in option) Keystone Correction Digital up to +/- 20° vertical, +/- 9° horizontal Video compatibility Component and RGB HDTV (720p, 1035i, 1080i, 1080p-24Hz)
Component EDTV (480p, 576p progressive scan)
SECAM: M, Component, composite and S-Video standard
video (480i, 576i, 576i RGB SCART with adapter, NTSC, NTSC M 4.43, PAL: B, G, H, I, M, N) Inputs 2 x components - gold RCA
2 x S-VHS - Mini Din 4-pin
1 x Composite Video - RCA
1 x DVI (M1-DA) - DVI HDCP or HDMI compliant with
optional adapter
1 x 15-pin D Sub (HDTV component/RGB, computer)
1 x RS232 control - 9-pin D Sub
1 x D5 (component)
1 x IR Repeater (Niles / Xantech compatible)
- 3.5 mm mini-jack
2 x 12 V trigger - 3.5 mm mini-jack Size Ř439 mm - Height 127 mm Weight 4.4 Kg Audible noise 25 dB Remote Control Infra-Red remote control Options Ceiling bracket horizontally and vertically adjustable
in white or black finish
M1DA to DVI adapter
M1DA to HDMI adapter Cabinet colour options Silver, White or Black
Enter the realm of HDTV with DreamwWeaver Plus !
When we develop a new product, we care as much about technology and performance as we care about Design. As a matter of fact, we understood that buying a a projector in our category is as much about performance as it is about feeling, emotion, life experience. That's why we want to promote Innovation, Design and Advanced Technology as the key parameters of DreamVision's range of products.
Highlights :
° State of the art Design for easy integration in every room style.
° True HD resolution (1280x720) from the Mustang HD2+ DLP chip by TI for the best resolution match for HD sources.
° Carl Zeiss Designed Light Engine.
° New DCDi from Faroudja with better colors sharpness, a video noise reducer and a high quality built-in Scaler.
° 8 selectable video inputs.
° Invisible access to the keypad board and connection board.
