Martin Logan


Frequency Response:
34–23,000 Hz ± 3dB

Horizontal Dispersion:
30 degrees
Vertical Dispersion:
40" (102cm) line source

92 dB/2.83 volts/meter

4 ohms, 1 at 20kHz

Crossover Frequency:
400 Hz

Custom-wound audio transformer, air core coils, polypropylene capacitors
Woofer Type:
8" (20.3cm) (per channel) cast basket, high excursion, aluminum cone with extended throw drive assembly, non-resonance asymmetrical chamber format, bass reflex
Woofer Amp Power:
200 watts/channel (4 ohms)
Bass Control:
±10dB at 35Hz
Power Handling:
250 watts per channel

Signal Inputs:
Custom bi-wire binding posts
Mains Power Draw:
Idle: 8W/channel
Max: 140W/channel
52 lbs./channel (23.6 kg)

Dimensions (HxWxD):
57" × 10.7" × 16.25" (144.7 × 27.3 × 41.3 cm)





Living in the shadow of a speaker as impressive as the Summit ™ is no easy thing. Vantage rises to the challenge by compressing Summit's groundbreaking ultra-high-resolution XStat ™ , AirFrame ™ , and PoweredForce ™ technologies into a surprisingly compact package – at a surprisingly compact price. What do you give up? Basically, about a half octave of low bass and some peak output capability. No fooling, it just knocks us out what the kid sis can do – you have to hear it to believe it.

XStat ™ Transducer

Advanced MicroPerf stator technology gives MartinLogan's latest-generation CLS ™ electrostatic transducer almost twice as much exposed diaphragm surface as a traditional electrostatic panel of the same size. This dramatic increase in effective radiating area translates to higher efficiency and an even more effortless, unlimited dynamic presentation. The XStat pulls no punches!

But there's more to it than just putting more holes in the stators, which must maintain uniform spacing in front of and behind the diaphragm to exacting tolerances. They cannot flex. XStat's ultra-rigid aluminum AirFrame ™ firmly anchors the transducer's working elements – stators and diaphragm – around their periphery, while ClearSpar ™ spacers stiffen the assembly further across its width. ClearSpars enable precise, consistent tensioning of the Vacuum Bonded diaphragm without obstructing the floating, see-through look that is the visual hallmark of MartinLogan electrostats.

In the end, a speaker cannot outperform the signal feeding it. MartinLogan's state-of-the-art toroidal transformer and electrical interface engineering ensure an absolutely transparent link from amplifier to electrostatic panel. The result is sound of unparalleled purity, precision, clarity, and openness – the next best thing to no speaker at all.

AirFrame ™ Technology

XStat ™ panels are secured to speaker cabinets using MartinLogan's AirFrame technology. AirFrames, manufactured from aerospace-grade billet and extruded aluminum alloy, make the panels extremely rigid without obstructing playable surface area or interfering with their dipole sound radiation. At the same time, they provide electrical and acoustical isolation, minimizing intermodulation distortion caused by vibration and resonance. Overall, AirFrames enhance imaging, low-level sonic detail, accuracy, and efficiency.

Vacuum Bonding

The components of each XStat ™ panel – two insulated, high-purity carbon steel stators, plasma-deposited PET diaphragm, and ClearSpar ™ spacers – are fused into a cylindrical-section geometry with an aerospace adhesive whose hold strength exceeds that of welding. Our proprietary Vacuum Bonding process ensures uniform diaphragm tensioning and facilitates the extremely tight tolerances necessary for construction of such a precision transducer.

Curvilinear Line Source Electrostatic Panel

One of MartinLogan's original breakthroughs, CLS ™ technology has been an essential ingredient of every electrostatic loudspeaker we've produced. Proprietary manufacturing methods enable construction of electrostatic panels as cylindrical sections. Their gentle horizontal curvature solves the problem of obtaining good high-frequency dispersion from a large radiating surface without compromising overall sound quality or reliability.

MicroPerf ™ Stators

Although stators are the elements of an electrostatic driver that are supposed to stand still, they carry the audio signals that do the work of propelling the diaphragm back and forth to move air and produce sound. Because the stators sandwich the diaphragm between them, they must be perforated to allow sound to pass through. Yet they must also be rigid enough to remain absolutely stationary despite the strong electrostatic forces pushing and pulling at them during operation.

MartinLogan's MicroPerf design optimizes this tradeoff by reducing the size of the individual holes and using many more of them than in a traditional electrostatic panel. MicroPerf almost doubles effective diaphragm radiating area without compromising structural integrity. The resulting increase in output capability and efficiency allows a panel to be made much smaller without sacrificing performance – or to enjoy a substantial leap in bandwidth and dynamics without growing larger.

PoweredForce ™ Bass

Vantage's PoweredForce woofer section harnesses an advanced 8-inch aluminum-cone driver, a 200-watt high-resolution amplifier, and a precision acoustic-control cabinet design to deliver stunning bass, down to 34 Hz, from an enclosure not much bigger than a case of wine. A 35-Hz level control allows easy, precise optimization of low-frequency output to room acoustics.

Low-Distortion Aluminum-Cone Woofers

By eliminating cone flexure, aluminum diaphragms help our advanced-technology woofers achieve the very low distortion necessary for proper blending with MartinLogan electrostatic panels.

Vojtko ™ Crossover

Carefully hand-built using only the finest polypropylene capacitors and air-core coils, the crossover employ's MartinLogan's proprietary Vojtko topology for vanishingly low distortion and seamless driver integration. This precision-tuned network preserves even the most microscopic sonic nuances while handling the full dynamics of any source.

Dipole Sound Radiation

The sound we hear from a loudspeaker is a combination of direct radiation from it to our ears and reflections off of room surfaces – walls, floor, and ceiling. How our brains integrate all this information is far from simple. Depending on the angle of incidence to the ears and the arrival-time difference between direct and reflected sound, reflections can either blur detail and stereo imaging or enhance the natural impression of depth and openness.

True dipole speakers, such as electrostatic panels, have long been noted for their near-ideal radiation patterns. They send very little sound to the sides, thereby minimizing side-wall reflections with short arrival times that tend to interfere with perception of the direct sound. Their strong rear radiation, however, produces a generous amount of ambience-enriching later-arriving reflections off the wall behind them.

Bi-wirable Toolless Binding Posts

MartinLogan's proprietary toolless binding posts make cable connection and management easy. Two sets are supplied, one connected to the crossover section feeding the electrostatic panel, the other to the section feeding the woofer. When the two are linked using the supplied straps, a conventional single-cable connection can be used. Or you can remove the straps for bi-wiring.

Energy Transfer Coupler Spikes

The Vantage is supplied with sturdy, 3/8-16 ETC ™ spikes, which can be used in place of the standard feet to enhance stability on thick carpets or to create tighter coupling between speaker and floor.

Finish Options

Available in a variety of hand-rubbed wood finishes, MartinLogan Vantage loudspeakers can be personalized to match any decor.
