Inputs
|
2 XLR (1 Constellation Link) |
|
2 RCA
|
|
|
Max power @ 0.1% THD+N, 20Hz-20kHz @ 8 Ω |
240W |
|
Max power @ 0.1% THD+N, 20Hz-20kHz @ 4 Ω
|
420W |
|
Input sensitivity @ power at 0.1% into 8 Ω
|
15V direct i/p, 3V non-direct |
|
Input sensitivity @ power at 0.1% into 4 Ω
|
12.5V direct i/p, 2.6V non-direct |
|
|
|
|
Outputs
|
Metal binding posts
|
|
Frequency response
|
10Hz - 80KHz +/- 0.05dB
|
|
Gain - direct input
|
12 dB
|
|
Gain - non-direct input
|
25.2 dB
|
|
AC power draw - standby
|
< 0.25W
|
|
AC power draw - idle
|
135W
|
|
AC power draw - @ max power in 8 Ω
|
1300W
|
|
AC power draw - @ max power in 4 Ω
|
1500W
|
|
Power factor - partial power
|
0.98
|
|
Power factor - full power
|
1 . 00
|
|
Damping factor
|
80
|
|
S/N ratio DC-90KHz ref 1 volt, A weighted
|
100dB
|
|
S/N ratio DC-90KHz ref full power, unweighted
|
115dB
|
|
S/N ratio DC-90KHz ref full power, A weighted
|
125dB
|
|
Output impedance
|
0.1Ω
|
|
Weight
|
43 lbs./19.5 kg
|
|
Dimensions
|
18.75"/476mm x 24.25/616mm x 11.5"/292mm (WDH)
|
Inspiration 2 Stereo and Mono amplifiers distill the power and passion of our original amplifiers into a more compact chassis. And now we’ve added C-SMPS, the best amplifier power supply ever created. The Inspiration 2 amplifiers use our Balanced Bridged technology: a musical, single-ended amplifier module. To achieve the desired output, we add modules rather than increasing circuit complexity. The result? Ample power to drive any speaker with the subtlety of a small amplifier.
The Inspiration 2 Stereo and Mono use the same Line Stage Gain Module input stage found in our top amplifiers. Hand-matched, low-noise transistors combine with a servo circuit that corrects any signal balance inconsistencies. The Inspiration 2 amplifiers’ Constellation Link interface connects to Constellation amplifiers to remove one amplification stage from the signal path, resulting in less complexity and more musicality.
The Inspiration 2 Stereo and Mono employ a balanced configuration, with separate amplifier circuits for the positive and negative halves of the audio signal. Other balanced amps use N-type transistors for the positive half of the circuit and P-type transistors for the negative half. Our Balanced Bridged configuration uses only N-type transistors, so both signal halves pass through the same circuitry, and even the softest musical details are preserved.
We like to think of the Inspiration 2 amplifiers as distilled versions of our larger models because the circuits and the core design philosophy are the same. They’re a perfect example of why our approach to amplification works so well. We didn’t have to redesign the amps to make them smaller; we just reduced the number of modules and made the power supply well, let’s say, a bit less overbuilt. When you hear what the combination of our innovative audio circuits and revolutionary C-SMPS power supply achieves, we expect you’ll be as astonished as the reviewers and showgoers who experienced the debut of these designs. The Inspiration 2 amplifiers may be smaller in stature, but their musicality and emotion are undiminished.
