Product name & number：Analog Relax EX2000 AR-MCC-EX2000
Transducer：MC Stereo Phono Cartridge
Output voltage：0.4mv (1kHz)
Impedance：8Ω
Stylus：SC Stylus Ver.3 Special custom order made solid diamond
Cantilever：Special nude diamond
Coil material：High Purity 6N copper
Body：Finest ‘spruce’ from the South Tyrol region of Northern Italy
Ultra-fine ‘powder coating’
Magnet：Multiple neodymium magnet
Weight：about 9.0g
We are pleased to announce the release of AR flagship model ‘Analog Relax EX2000 Phono Cartridge’ which features a diamond cantilever. The EX2000 uses the finest ‘spruce’ from the South Tyrol region of Northern Italy, where the material for the ‘Stradivarius’ is said to have been harvested. Its surface is coated with an ultra-fine powder allowing it to reproduce the natural sound.
The finest spruce harvested from the same forest as “Stradivarius”
AR use the finest “spruce” for the body shell that is harvested in the northern Italian South Tyrol region and used as the top wood for violins.
he northern Italian South Tyrol region is said to be the forest area where materials for the renowned “Stradivarius” were harvested. We carefully select and cultivate the highest quality spruce from this area, and it undergoes rigorous management during the drying process.
A precision-machined “diamond” cantilever
A precision-machined “diamond” cantilever is used to seamlessly transmit the movement of the record’s grooves to the power generator, bringing out high-resolution sound. In addition, compared to diamond cantilever models of other manufacturers, by cutting out the diamond cantilever slightly thicker, we have achieved a more solid sound and improved traceability at a higher level.
Evolved version of custom-developed SC stylus Ver.3
The stylus is the ‘Ver. 3’ model, which is a further evolution of the well-received ‘SC stylus’ used for the EX1000. Of course, the stylus is custom-developed by Analog Relax. Although it basically has a line contact shape, a number of multi-faceted cuts are applied vertically, allowing it to reproduce sound with almost no ‘inner distortion’. In addition, the front and back of the stylus tip are cut with different curvatures, making it difficult to pick up the “crackling noise” peculiar to original records and old pressed records, enabling playback with a very high signal to noise ratio.
Cartridges with a diamond cantilever typically ‘pick up lots of information but with a tense and edgy sound’ which prevents the listener to enjoy the record. The EX2000 was completed by utilizing advanced assembly techniques to achieve a sound that has depth, range, and substance, while remaining the full amount of the groove information.
